KT99 guitar receiver

Frequency range: 500-980mhz

Band width :12MHz/36MHz

PLL frequency synthesis technology

Frequency stability: ±3ppm

Frequency response :50-16000Hz

SNR :>105dB(12dB S/N AD)

Distortion :<0.5% @ 1KHz

Mute mode: noise lock noise control +

Audio output voltage :-12dB

Input voltage :DC 3V 450mA

Batteries :2 AA 1.5V alkaline batteries

Battery life: ≥6h

Volume :(L)125 X (W)78 X (H)43mm

Weight (including battery): 205G



Launch parameters

Frequency range: 500-980mhz

Band width :12MHz/36MHz,32/96 channels

PLL frequency synthesis technology

Frequency stability :±3ppm

Transmitting output power :5mW

Side wave suppression :<-60 DBC

Maximum offset: ±45KHz

Frequency response :50-16000Hz

Distortion :<0.5% @ 1KHz

External sensitivity :0dB or -10dB

Battery :1 AAA 1.5V alkaline battery

Battery life :≥6h

Weight: 55 g
